Synology DiskStation DS1621+ NAS AMD V1500B quad-core 2.2 GHz 4GB DDR4 3xUSB 3.2 Gen 1 2xeSATA 6 bay (DS1621+)

Favorite
Compara

Data management and protection, for anyone.

Pretul afisat contine TVA (19%).

5.973,00 lei

Compara

Synology DiskStation DS1621+ NAS AMD V1500B quad-core 2.2 GHz 4GB DDR4 3xUSB 3.2 Gen 1 2xeSATA 6 bay



  • Powerful, scalable, and versatile
    Synology DS1621+ is a powerful and compact 6-bay network attached storage solution designed to store and protect critical data assets. Designed for scalability, the DS1621+ enables you to start small and expand as your data grows.
  • Faster than ever
    DS1621+ is faster in just about everything. Get things done quicker and streamline photo management.
  • Turbocharge and expand it
    Upgrade your DS1621+ to match your data requirements, whether it is for faster networking or for higher storage capacity.
  • Ultimate backup solution
    DS1621+ integrates various backup applications into an intuitive user interface, offering durable storage technologies to safeguard your valuable data on any device.
Produs:
Nume produs: SYNOLOGY DS1621+ NAS AMD V1500B quad-core 2.2 GHz 4GB DDR4 3xUSB 3.2 Gen 1 2xeSATA 6 bay
Descriere: Synology Disk Station DS1621+ – NAS server – 6 bays – SATA 6Gb/s – RAID RAID 0, 1, 5, 6, 10, JBOD – RAM 4 GB – Gigabit Ethernet – iSCSI support
EAN: 4711174723775
Garanție: 36 Luni
 General
Device Type: NAS server
Host Connectivity: Gigabit Ethernet
Installed Devices / Modules Qty: 0 (installed) / 6 (max)
Width: 28.2 cm
Depth: 24.3 cm
Height: 16.6 cm
Weight: 5.1 kg ()
Enclosure Colour: Black
Built-in Devices: Led panel
 Processor / Memory
Processors Installed: 1 x AMD Ryzen Embedded V1500B 2.2 GHz
Number of Cores: Quad-Core
Max Supported Qty: 1
RAM: 4 GB (installed) / 32 GB (supported) – DDR4
 Storage Controller
Type: RAID
Interface Type: SATA 6Gb/s
RAID Level: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD
 Networking
Data Link Protocol: 10Mb LAN, 100Mb LAN, GigE
Network / Transport Protocol: iSCSI
Remote Management Protocol: SNMP, Telnet, HTTP, HTTPS, TFTP, SSH
Network Services Compatibility: Microsoft Active Directory (AD), File Level Security (ACLs), Microsoft CIFS, Network File System (NFS), FTP, Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV)
Features: Hardware encryption, VPN support, wake on LAN (WOL), Syslog support, High Availability, download client, file sharing, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, surveillance station, PXE support, DLNA Media Server, Apple Time Machine compatible, WebDAV server, VPN Server, anti-virus protection, Link Aggregation, failover protection, DLNA support, OpenStack compatible, SSD trim, iSCSI LUN clone/snapshot, Windows ODX, cloud station server, MailPlus server, Rsync compatible, Synology Hybrid RAID
Compliant Standards: DLNA CERTIFIED
 Expansion / Connectivity
Expansion Bays: 6 (total) / 6 (free) x hot-swap – 2.5″ / 3.5″
Expansion Slots: 2 (total) / 1 (free) x DIMM 288-pin
2 (total) / 2 (free) x M.2 2280
1 (total) / 1 (free) x PCI Express 3.0 x8
Interfaces: 3 x USB 3.0 – Type A
4 x Ethernet 1000Base-T – RJ-45
2 x eSATA
 Miscellaneous
Cables Included: 2 x network cable
Features: Security lock slot (cable lock sold separately), wake on LAN, built-in 2 cooling fans, Citrix Ready, VMware Ready
Security Slot Type: Kensington security slot
Compliant Standards: VCCI, BSMI, CCC, FCC, RoHS, EAC, RCM
Included Accessories: Accessory pack
 Power
Power Device: Internal power supply
Voltage Required: AC 120/230 V (50/60 Hz)
Power Consumption Operational: 51.22 Watt
Power Consumption Stand by: 25.27 Watt
Power Provided: 250 Watt
 Software / System Requirements
Software Included: McAfee AntiVirus, Synology Central Management System
 Manufacturer Warranty
Service & Support: Limited warranty – 3 years
 Environmental Parameters
Min Operating Temperature: 0 °C
Max Operating Temperature: 40 °C
Humidity Range Operating: 5 – 95%
Sound Emission: 25.2 dBA
SKU: DS1621+ Categorii: , , ,
  • Hardware Specs

CPU

 CPU Model AMD Ryzen V1500B
CPU Architecture 64-bit
CPU Frequency 4-core 2.2 GHz
Hardware Encryption Engine (AES-NI)

Memory

 System Memory 4 GB DDR4 ECC SODIMM
Memory Module Pre-installed 4 GB (4 GB x 1)
Total Memory Slots 2
Maximum Memory Capacity 32 GB (16 GB x 2)
Notes
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • For more information on the recommended memory configurations, visit here.
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

 Drive Bays 6
Maximum Drive Bays with Expansion Unit 16 (DX517 x 2)
M.2 Drive Slots 2 (NVMe)
Compatible Drive Type* (See all supported drives)
  • 3.5″ SATA HDD
  • 2.5″ SATA HDD
  • 2.5″ SATA SSD
  • M.2 2280 NVMe SSD
Maximum Single Volume Size* 108 TB
Hot Swappable Drive
Notes
  • „Compatible drive type” indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • Each internal volume (may consist of multiple drives) is expandable up to 108TB.

External Ports

 RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
USB 3.0 Port 3
eSATA Port 2

PCIe

 PCIe Expansion 1 x Gen3 x8 slot (x4 link)

File System

 Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
Notes exFAT Access is purchased separately in Package Center.

Appearance

 Size (Height x Width x Depth) 166 mm x 282 mm x 243 mm
Weight 5.1 kg

Others

 System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 25.2 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 250 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 51.22 W (Access)
25.27 W (HDD Hibernation)
British Thermal Unit 174.77 BTU/hr (Access)
86.22 BTU/hr (HDD Hibernation)
Notes
  • Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

 Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH

Certification
  • EAC
  • VCCI
  • CCC
  • RCM
  • KC
  • FCC
  • CE
  • BSMI

Warranty

 3-year hardware warranty, extendable to 5-year coverage – EW201
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

 RoHS Compliant

Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1

Optional Accessories
Notes All memory modules will operate at the maximum frequency specified by the CPU manufacturer.
