ZYXEL XGS2220-30F, L3 Access Switch (XGS2220-30F-EU0101F)
Specificatii
Certificates
Compliance certificates
RoHS, Federal Communications Commission (FCC), Low Voltage Directive (LVD), CE
Design
LED indicators
Yes
Product colour
Black
Rack mounting
Yes
Management features
Switch layer
L3
Cloud-managed
Yes
ARP inspection
Yes
Web-based management
Yes
Switch type
Managed
Quality of Service (QoS) support
Yes
Network
Routing entries
64
Multicast support
Yes
10G support
Yes
Static route
Yes
Power over Ethernet (PoE)
No
Packaging data
Package width
616 mm
Package depth
355 mm
Package weight
4.83 kg
Package height
107 mm
Ports & interfaces
Installed SFP+ modules quantity
4
10G Ethernet (copper) ports quantity
2
Basic switching RJ-45 Ethernet ports type
No
Power over Ethernet (PoE)
No
Security
MAC address table
32000 entries
Authentication type
IEEE 802.1x, RADIUS, TACACS+
Security algorithms
SNMP, SNMPv2, SNMPv3
BPDU filtering/protection
Yes
IGMP snooping
Yes
DHCP features
DHCP relay, DHCP server
IGMP proxy
Yes
Ungrouped
Installed SFP+ modules quantity
4
Extra info
LAN-Port-Type
Gigabit
Data transmission
Switching capacity
168 Gbit/s
Forwarding rate
125 Mpps
MAC address table
32000 entries
Packet buffer memory
2 MB
Jumbo frames support
Yes
Static route
Yes
Features
Product colour
Black
LED indicators
Yes
Quality of Service (QoS) support
Yes
Mean time between failures (MTBF)
352.923 h
Flash memory
64 MB
Multicast features
Multicast support
Yes
Multicast Listener Discovery (MLD) snooping
MLD v1/v2
Operational conditions
Operating temperature (T-T)
-20 – 50 °C
Operating relative humidity (H-H)
10 – 95%
Storage relative humidity (H-H)
10 – 90%
Storage temperature (T-T)
-40 – 70 °C
Heat dissipation
225.06 BTU/h
Performance
Mean time between failures (MTBF)
352.923 h
Flash memory
64 MB
Power
Power source
AC
Power over Ethernet (PoE)
No
Power supply included
Yes
AC input voltage
100 – 240 V
Power consumption (typical)
66 W
AC input frequency
50 – 60 Hz
Protocols
GARP VLAN Registration Protocol (GVRP)
Yes
Technical details
Compliance certificates
RoHS, Federal Communications Commission (FCC), Low Voltage Directive (LVD), CE
Weight & dimensions
Weight
3.5 kg
Width
441 mm
Height
44 mm
Depth
270 mm
