Digital Signage, Open Frame LCD Display
Pretul afisat contine TVA (19%).
SYN 17.3″ Full HD Touch Screen Open Frame LCD Display Monitor with HDMI in
digital signage equipment
Compara
SYN 17.3″ Full HD Touch Screen Open Frame LCD Display Monitor with HDMI in
| Size: | 19inch | LCD Brand: | LG, Samsung, AUO A Level |
|---|---|---|---|
| Resolution: | 1280*1024 | Type: | Open Frame |
| Privacy Film: | Brand: 3M, 60 Degree Viewing Angle | Display Area: | 380*305mm |
| Monitor Interface: | In, VGA In, DVI In | ||
| High Light: | pen frame lcd monitor,
open frame lcd panel |
||
Product Description
Viewing Angle Open Frame Touch Screen Monitor / Tailor Made Digital Custom Lcd Display
This is tailor-made open frame with 10-point PCAP touch screen and 3M brand 120 degree viewing angle touch monitor, interface of in, DVI in and VGA in, meet user’s various usage. Client inbuilt it into their own frame, touch screen size is customized.
Installation bracket is on option, intallation holes will be prepared in the housing and with our L-shaped bracket, client to choose how and where to install on site.
| Specification | ||||
| Model No. | MO-190 | |||
| Panel size | 19″ TFT-LCD panel with LED backlight | |||
| Display area(mm)/mode | 380mm(H)×305mm(V) 4:3 | |||
| Max Resolution | 1280×1024 | |||
| Display color | 16.7M | |||
| Pixel Pitch(mm) | 0.294mm(H) x 0.294mm(W) | |||
| Brightness (nits) | 300cd/m2 | |||
| Contrast | 1000:1 | |||
| Visual angle | 178°/178° | |||
| Response time | 5ms | |||
| Life(hrs) | >60,000(hrs) | |||
| Detailed functions | ||||
| Video formats | MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD: DAT/MPG1) | |||
| Audio format | Wave/MP3/WMA/AAC | |||
| Image formats | JPEG/BMP/TIFF/PNG/GIF | |||
| Image resolution | 480P/720P/1080P | |||
| OSD display( screen menu display) | ||||
| Menu language | Chinese/English( Multiple Language Supported) | |||
| Power | ||||
| Power supply | DC 12V, adapter provided by buyer | |||
| Maximum power consumption | ≦60W | |||
| Standby power consumption | <5W | |||
| Temperature | ||||
| Working temperature | 0℃～50℃ | |||
| Storage temperature | -20℃～60℃ | |||
| Working humidity | 20%~85% | |||
| Storage humidity | 10%~90% | |||
| Appearance | ||||
| Color/appearance | Black/silver/White | |||
| decor glass | 3mm glass | |||
| Installation | open frame | |||
| Touch screen | 10-points PCAP touch screen | |||
| Mainboard | ||||
| Mainboard | in*1, VGA in*1, DVI in*1 | |||
| Accessory | Power Cables, English Manual | |||
