SYN Widescreen HD Open Frame Touch Screen Monitor For Indoor Multimedia


digital signage equipment

Pretul afisat contine TVA (19%).

Compara

SYN Widescreen HD Open Frame Touch Screen Monitor For Indoor Multimedia

Size: 10.4 Inch Screen: Industrial A + Grade LCD Panel
Resolution: 800 * 600 Type: Open Frame
Viewing Angle: 140°/150° Display Area: 214mm(W)*160mm(H)
Aspect Ratio: 4:3
High Light: open frame lcd panel,

open frame displays



Product Description





Widescreen HD Open Frame LCD Display 10.4″ for Indoor Multimedia



  • 4:3 Aspect Ratio
  • USB2.0, or VGA interface is optional
  • Standard VESA install mount.
  • Professional appearance design,delicate and generous.
  • Industrial A+ grade LCD panel
  • Intelligence temperature control fan design,green and quiet.
  • VGA image reproduction rate



Description:

  1. Ultra-slim design,convenient use,delicate appearance.
  2. Industrial A+ grade LCD panel
  3. High contrast,High brightness,vivid image layout,bets details performance.
  4. Auto eliminate blur function,long life span.
  5. Auto adjust VGA image reproduction rate.
  6. Multiple date-image adjustment circuit,low image distortion.
  7. Wide visual angle 178°,aspect ratio 4:3
  8. Rich signal input,output interfaces,adapted in the different environments.
  9. Appling the latest 3D digital image decode chipset,the latest DNR,image clear,clean and vivid.
  10. Intensive the IR receiver,support the IR remote to modify the monitor parameters.
  11. Build-in stable power,low consumption,long life span>60000hours





Specifications:



Technical Parameter for LCD Panel

product 10.4″ HD Open frame LCD Monitor
model MP-104
Screen type 10.4″ TFT LCD
Display area 214(W)×160(H)
Aspect ratio 4:3
resolution 800×600
Number of colors 16.7M
Dot pitch 0.264(H)×0.264(V)
brightness 350cd/㎡
contrast 450:1
Viewing angle 140°/150°
Response time 5ms
HF 31k~48kHZ
VF 56~60HZ
color system PAL/NTSC/SECAM
Signal interface Input:2*BNC,1*VGA,1*AUDIO output:1*BNC
voltage DC  12V/2A
On mode ≤18W
Standby model ≤1W
Working temperature 0°~50°
humidity 20%~80%
Life 60000H
color Black/white/customized
installment Desktop/wall mounted
certification CE/3C/FCC/UL
Dimension 238.4×192.4×35
Net weight 1.8KG





Competitive Advantage:



Indoor multimedia LCD monitor with an open frame design,you can design the front cover according to your exact project.Mostly customers install this open frame LCD ad player under tables or inside walls or inside their own machines to make full use of its open frame feature perfectly.With slim frame design is available.
