ZYXEL GS1200-5HP 5-PORT GBE METAL SWITCH (GS1200-5HPV2-EU0101F)
Specificatii
Certificates
Certification
CE, FCC, C-Tick, Class A
Design
Stackable
No
On/off switch
Yes
Reset button
Yes
Rack mounting
No
Safety
LVD EN60950-1
LED indicators
Link, PoE, Power
Certification
CE, FCC, C-Tick, Class A
Logistics data
Harmonized System (HS) code
85176990
Multicast features
Multicast support
Yes
Number of multicast groups filtered
20
Operational conditions
Storage relative humidity (H-H)
10 – 90%
Operating temperature (T-T)
0 – 40 °C
Storage temperature (T-T)
-40 – 70 °C
Operating relative humidity (H-H)
10 – 90%
Performance
Firmware upgradeable
Yes
Power
Output current
1.3 A
Power over Ethernet (PoE)
Yes
Power consumption (max)
72 W
Security
MAC address table
2000 entries
IGMP snooping
Yes
DHCP features
DHCP client
Extra info
LAN-Port-Type
Gigabit
Data transmission
Packet buffer memory
0.1 MB
Jumbo frames
9000
MAC address table
2000 entries
Store-and-forward
Yes
Switching capacity
10 Gbit/s
Jumbo frames support
Yes
Features
Certification
CE, FCC, C-Tick, Class A
LED indicators
Link, PoE, Power
Flow control support
Yes
VLAN support
Yes
Quality of Service (QoS) support
Yes
Management features
Reset button
Yes
Web-based management
Yes
Switch type
Managed
Quality of Service (QoS) support
Yes
Firmware upgradeable
Yes
Network
Virtual LAN features
Port-based VLAN
Auto MDI/MDI-X
Yes
Flow control support
Yes
10G support
No
Broadcast storm control
Yes
Multicast support
Yes
Full duplex
Yes
Port mirroring
Yes
VLAN support
Yes
Power over Ethernet (PoE)
Yes
Link aggregation
Yes
Packaging data
Package depth
132 mm
Package type
Box
Package weight
950 g
Package width
210 mm
Package height
7.8 mm
Ports & interfaces
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power over Ethernet (PoE) ports quantity
5
Basic switching RJ-45 Ethernet ports quantity
5
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
5
Power over Ethernet plus (PoE+) ports quantity
4
Total Power over Ethernet (PoE) budget
60 W
Weight & dimensions
Weight
392 g
Depth
84 mm
Width
193 mm
Height
26 mm
