ZYXEL GS1200 8-Port Web Managed PoE Gigabit Switch (GS1200-8HPV2-EU0101F)
Descriere
Specificatii
Data transmission
Jumbo frames support
Yes
Jumbo frames
9000
Store-and-forward
Yes
Switching capacity
16 Gbit/s
MAC address table
4000 entries
Jumbo frame range
1 – 1 B
Features
Flow control support
Yes
Quality of Service (QoS) support
Yes
Networking standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x
Management features
Web-based management
Yes
Switch type
Managed
Quality of Service (QoS) support
Yes
Operational conditions
Operating relative humidity (H-H)
10 – 90%
Storage temperature (T-T)
-40 – 70 °C
Storage relative humidity (H-H)
10 – 90%
Operating temperature (T-T)
0 – 40 °C
Performance
Buffer size
192 KB
Power
Power consumption (max)
72 W
Input current
1.3 A
Power over Ethernet (PoE)
Yes
DC input voltage
55 V
Security
IGMP snooping
Yes
Loop protection
Yes
DHCP features
DHCP client
MAC address table
4000 entries
Weight & dimensions
Weight
584 g
Depth
105 mm
Width
240 mm
Height
26 mm
Design
Housing material
Metal
Stackable
No
Number of fans
0 fan(s)
Rack mounting
No
Logistics data
Harmonized System (HS) code
85176990
Network
Auto MDI/MDI-X
Yes
Flow control support
Yes
Port mirroring
Yes
Full duplex
Yes
Link aggregation
Yes
Power over Ethernet (PoE)
Yes
Networking standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x
Broadcast storm control
Yes
Packaging data
Package depth
132 mm
Package width
256 mm
Package weight
1.15 kg
Package height
7.8 mm
Ports & interfaces
Installed SFP+ modules quantity
0
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power connector
DC-in jack
Basic switching RJ-45 Ethernet ports quantity
8
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity
4
Total Power over Ethernet (PoE) budget
60 W
Power over Ethernet (PoE)
Yes
Ungrouped
Installed SFP+ modules quantity
0
Extra info
Rackable
Yes
LAN-Port-Type
Gigabit
Redundant-PSU
No
Layer
Layer-2
LAN-Ports
48
