Certificates
Certification
LVD, BSMI FCC 15 A, CE EMC A, BSMI ENC RoHS A
Design
Certification
LVD, BSMI FCC 15 A, CE EMC A, BSMI ENC RoHS A
Product colour
Black
Rack mounting
Yes
Logistics data
Harmonized System (HS) code
85176990
Multicast features
Multicast support
Yes
Operational conditions
Operating relative humidity (H-H)
10 – 95%
Storage temperature (T-T)
-40 – 70 °C
Operating temperature (T-T)
0 – 50 °C
Storage relative humidity (H-H)
10 – 95%
Heat dissipation
718.828 BTU/h
Packaging data
Package depth
235 mm
Package weight
2.7 kg
Package height
61 mm
Package width
375 mm
Ports & interfaces
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
10
Installed SFP+ modules quantity
0
Power over Ethernet (PoE) ports quantity
8
Combo SFP ports quantity
2
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
8
Total Power over Ethernet (PoE) budget
180 W
Ungrouped
Installed SFP+ modules quantity
0
Extra info
LAN-Port-Type
Gigabit
Data transmission
MAC address table
16000 entries
Packet buffer memory
1.5 MB
Switching capacity
20 Gbit/s
Forwarding rate
15 Mpps
Features
VLAN support
Yes
Internal memory
256 MB
Quality of Service (QoS) support
Yes
Product colour
Black
Certification
LVD, BSMI FCC 15 A, CE EMC A, BSMI ENC RoHS A
Flash memory
32 MB
Flow control support
Yes
Rate limiting
Yes
Mean time between failures (MTBF)
587477 h
Management features
Quality of Service (QoS) support
Yes
Web-based management
Yes
System event log
Yes
Switch type
Managed
Firmware upgradeable
Yes
Switch layer
L2
Configuring Location Settings (CLI)
Yes
Network
Multicast support
Yes
Copper ethernet cabling technology
10BASE-TX, 1000BASE-T
Virtual LAN features
Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
10G support
No
Broadcast storm control
Yes
Spanning tree protocol
Yes
Flow control support
Yes
Rate limiting
Yes
VLAN support
Yes
Link aggregation
Yes
Power over Ethernet (PoE)
Yes
Packaging content
Cables included
AC
Performance
Noise level
41 dB
Flash memory
32 MB
Internal memory
256 MB
Firmware upgradeable
Yes
Mean time between failures (MTBF)
587477 h
Power
AC input frequency
50 – 60 Hz
AC input voltage
100 – 240 V
Power over Ethernet (PoE)
Yes
Power consumption (max)
210.8 W
Security
MAC address table
16000 entries
DHCP features
DHCP client, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay
Security algorithms
SNMP, SNMPv2, SNMPv3, SSH-2, SSL/TLS
Authentication
Guest VLAN, MAC-based authentication
IGMP snooping
Yes
Authentication type
IEEE 802.1x, RADIUS
MAC address filtering
Yes
Access Control List (ACL)
Yes
Weight & dimensions
Depth
162 mm
Width
267 mm
Weight
1.8 kg
Height
44 mm
